This section summarizes the overall health of the cluster. A cluster is simply a set of nodes (individual computers) that are physically connected (via a network) and logically coordinated by Kubernetes. This cluster is composed of four nodes. The following visualizations illustrate the health and availability of those nodes, their total resource capacity, and the number of Kubernetes resources currently running in the cluster.

Here we can see the actual CPU and memory usage of the whole cluster. The two panels on the top show the current state, whereas the charts below it show usage over time. You can change the time-frame to see it over the course of a month, etc.

Lastly, in this section we can see the network activity of the cluster and of the EC2 instance. The EC2 machine is an Amazon Web Services virtual machine: I use it as the internet-facing entrypoint of the cluster. Amazon provides DDOS protection and basic security for its virtual machines by default, which makes it ideal for such a purpose. It's also very cheap (currently free for me). The top panel is the network activity of my cluster itself, whereas the panels below that are the network activity (specifically packets in) and CPU usage of the EC2 instance. I have identified (you can see better if you adjust the time range) limits that indicate suspiciously high network activity.

The diagram below shows the system’s overall design. An Amazon EC2 instance functions as the system’s entry point and forwards requests from the internet over a private, encrypted Tailscale network: this connection links the EC2 directly to the cluster nodes without exposing internal services to the public internet. Inside the cluster, Kubernetes handles the ongoing operation of applications. It ensures that services continue to run even in the event of node outages, etc. The data flow goes as follows: Caddy receives requests from the public internet and handles automatic HTTPS and certificate management (so the website can be https://). The requests are then forwarded over a VPN connection (Tailscale) into the cluster via the Tailscale gateway pod, and passed to an internal Nginx instance where it is then routed to the correct service.

In the course of creating and managing this system I have made an effort to stick to best-practice behaviour. The most important example is the use of declarative frameworks such as Terraform and ArgoCD. Just to explain a bit: Terraform is a framework that is used to provision and manage cloud resources (EC2 instances, domain names, CloudFront, etc.) in code. In other words, it allows users to maintain infrastructure explicitly and declaratively in code rather than having to fidget around in, say, the AWS web interface. Along the same lines, ArgoCD is used to keep a Kubernetes cluster's state declarative: yaml files are kept in a git repository (on GitHub, etc.) which ArgoCD continually monitors and works to ensure that the cluster state matches that which is specified. The key idea here is the externalization of infrastructural information. There is nothing to forget and no tedious steps to repeat if the information is simply declared and the system itself (Terraform, ArgoCD) works to maintain the desired state. Importantly, it also allows for versioning of infrastructure. If you ever make a mistake, for instance, you can simply roll back to the past stable version. This capability has saved my skin a few times.

Just for fun, here is a chart of the total visits to this site over time.
